Reflect Perfect Turning Ability!

Artistic design with complete extended function!!

  • Suittable for machining optical element medical care appliances, automobile (motorbike), aviation (aerospace) and electronic component.
  • The FTC series CNC Lathe not only provide high stability but also had elegant design, increases production efficiency tremendously.


Back Download

B:Box Way   L:Linear Guide Way

MODEL UNIT FTC-26B (L)
Swing Over Bed mm 600
Swing Over Top Slide mm 380
Distance Between Center  mm 625/925/1225
MAX. Turnable O.D. mm 250
MAX.Turnable Length mm 600/850/1150
Angle of the Machine bed  Degree 30
AC Spindle Motor   18.5KW/25HP
Max. Spindle Speed RPM 3000
Spindle nose ISO A2-8
Spindle Hole mm 92  (105  OPT)
Through Bar Capacity mm 75  (92  OPT)
Spindle Front Bearing I.D. mm 130
Chuck Size inch  10"
Tailstock Taper MT MT#4/MT#5(OPT)
Tailstock Quill Diameter mm 80
Tailstock Quill Travel mm 80
Tailstock Seat Travel mm 550/850/1150
X-Axis Travel mm 165+40
Z-Axis Travel mm 600/900/1200
X-Axis Rapid Speed m/min 20
Z-Axis Rapid Speed m/min 20
Min. Input Increment mm 0.001
Square Shank Tools Size mm 25
Max. Boring Tool Diameter mm 40
Numbers of Tool Position 　 10(12 OPT)
Change Tool Times sec 1.2
Coolant Pump Motor HP 1 1/2
Machine Dimension mm³ 3000*1900*1950
Floor Space mm² 3600*2500
Packing Dimension mm³ 4000*2290*2150
Machine Net Weight kg 5200/5700/6250
Machine Gross Weight kg 5650/6200/6850
  • Work-piece conveyor
  • Tool length measurement
  • Oil mist filter
  • Oil skimmer
  • C-axis function
  • Auto power off
  • Porgrammable tailstock
  • VDI turret
  • Index type Dia.52/60mm collet chuck
  • Transformer



  • 8" Hydraulic chuck
  • 10 tools servo turret
  • Tool station facing holder 1 set
  • Boring bar tool holder 4 sets
  • ID Sleeves 10, 12, 16, 20, 25, 32mm/each 1 pc
  • Soft Jaw
  • Hydraulic tailstock
  • Removable coolant tank
  • Chip conveyor with remove cart
  • Centralized lubrication system
  • Heat exchanger for electrical cainet
  • Foot Switch
  • RS-232 interface
  • Work lamp
  • Warning lamp
  • Leveling bolts & pads
  • Tool box
  • Machin, electrical and instruction manual
  • Bar Feeder Interface



FTC-26B Box Way

FTC-26L Linear Guide Way
